德国MANNESMANN DEMAG气动马达-MUD9系列： 功率4.4KW，扭矩从15-1126Nm，转速0-2800转/分钟，耗气量5L/S。 型号 功率 负载转速 负载扭矩 启动扭矩 最大扭矩 空载转速 耗气量 重量 KW RPM Nm Nm Nm RPM m³/min Kg. MU600-2800 4.4 2800 15 22.5 30 5600 5 13 MU600-1400 4.4 1400 30 45 60 2800 5 13 MU600-750 4.4 750 57 85.5 114 1500 5 18 MU600-500 4.4 500 85 127.5 170 1000 5 18 MU600-250 4.4 250 170 255 340 500 5 18 MU600-75*V 4.4 75 563 844.5 1126 150 5 19.5 The modelsMUB600are equipped with afriction force brake with spring load. This brake is controlled by a seperate control air line which must receive compressed air earlier than the motor itself. The break guide air line must receive at least 4,8bar to release the brake(no pressure means the brake is applied.
